CYE098 Dental Multi-frequency High Accuracy Endodontic Apex

1. Advanced multi-frequency network technology of apex location and automatic calibrating ensures the measurements are accurate.
2. The File clip, Lip hook and Touch tip can be sterilized by autoclaved sterilizer.
3.The buzzer will alert when the file is less than 2mm closed to the apex.
4. Compact size and stable design allows for excellent flexibility during procedures.
5.It is not necessary to set the device on zero before measuring each individual canal

1. Dimensions(mm): 52 × 66 × 110 (L*W*H)
2. Weight: 330g
3. Battery: 3.7V/750mAh
4. Adapter: 5V/1A
5. Screen: 3.2 inch LCD
6. Consumption power: ≤0.5W
7. Buzzer alert: The buzzer will alert when the file is less than 2mm closed to the apex.
8. Operation condition
a) Environment temperature: 0～40℃
b) Relative humidity: 10～85%RH.
c) Atmosphere pressure: 60kPa～106kPa

1. Root canal working length determination during endodontic therapy
2. Assists root canal preparation before filling
3. Clinical dental clinic root‑canal diagnosis & measurement
4. Dental hospital, private dental practice endo treatment
5. Dental teaching simulation training
